Model:

O’Brien CN-2

CPU:

Intel Centrino Mobile Technology

- Intel Pentium M Processor 700 Series 1.4 to 2.0GHz with 1MB/2MB Cache

- Intel Celeron Processor 300 Series 1.2 to 1.4GHz

Chipset:

Intel 855PM + ICH4-M Chipset or Intel 852GML +ICH4-M

Front Side Bus:

400MHz

Memory:
- 2 SO-DIMM slots with 2GB DDR SDRAM Max.
- DDR SDRAM 266MHz, PC2100 Modules 2.5v

Display:

- TFT Active Matrix Color LCD display
- Available Sizes (diagonal) 15.0" XGA+
- Maximum LCD Resolution 1024 x 768, 16.7 million colors

Graphics:

Intel 855GM Embedded with shared memory options up to 64MB

Audio:

- AC ’97 stereo sound with 3D sound effects; full duplex audio
- Two Internal Stereo Speakers

HDD Support:

- 2.5" 9.5mm height, Enhanced IDE, ATA-100/133 support
- Available Capacities 80GB, 60GB, 40GB & 30GB

DVD/CD-RW Combo:

Optical Drive 24X10X8X +24X Combo CD-RW+DVD

Wireless (Optional)

- Embedded WLAN dual-band antenna;

- Intel PRO/Wireless 2100, IEEE 802.11 b

- Intel PRO/Wireless 2200BG, IEEE

- 802.11 b+g

Modem/LAN:

- 56K Soft Modem, V.90/92 support

- 10/100 Ethernet Base T onboard

Wireless (Optional):

- Embedded WLAN dual-band antenna; Intel PRO/Wireless 2100, IEEE 802.11 b

- Intel PRO/Wireless 2200BG, IEEE 802.11b+g

Card Reader:

4-in-1; supports SmartMedia, MultiMediaCard, Memory Stick, and Secure Digital

I/O Devices:

- PCMCIA 2.1; supports one Type II card

- Touch pad with two-click buttons and scroll wheel function

- 86/87/88 full-sized keyboard with 19 x 19mm key caps, 2.5mm travel; Microsoft Windows function keys; and palm rest

I/O Ports:

1 - IEEE 1394 Port

2 - Audio Jacks: Mic-In and Speaker Out

1 - VGA Port/Mini D-sub 15-pin for external monitor

5 - USB 2.0 Ports

1 - PS/2 Port

1 - RJ11 Modem Connector

1 - RJ45 Ethernet Connector

1 - DC-In Connector

AC/DC Adapter:

- Output: 19V DC, 3.15A, 60W
- Input: 100~240V AC, 50/60Hz Universal

Primary Battery:

- Lithium Ion, 4-Cell, 2200mAh battery

- Approximately 2 hours; charging time > 2 hours (power off), 2 hours (power on)

Dimensions:

- 13.0 x 10.5 x 1.3 inches
- 330 x 268 x 34 mm

Weight:

6.2 lbs. / 2.8 kg

Warranty:

Three year limited warranty for parts, labor and technical support
