Notebook Highlights:
- Intel® Pentium® M processor up to 1.9GHz
- 15” SXGA TFT Display; 1400 x 1050 resolution; 16.7 million colors
- Optical Drive 24X10X8X +24X Combo CD-RW+DVD
- AGP 4X interface with ATI Mobility Radeon 9600, 64MB 266MHz DDR embedded memory
- 4-in-1Flash Reader/Writer Slot; supports SmartMedia, MultiMediaCard, Memory Stick, and Secure Digital
Detailed Specifications:
Model:
O’Brien CN-6
CPU:
Intel Centrino Mobile Technology
- Intel Pentium® M Processor 1.4GHz to 1.9GHz
Chipset:
Intel® 855PM + ICH4-M Chipset
Front Side Bus:
400MHz
Memory:
- 128MB to 2GB; 333MHz DDR SDRAM
2 - SO-DIMM sockets with 0MB memory onboard
Display:
- TFT Active Matrix Color LCD display
- 15” SXGA TFT display; 1400 x 1050 resolution; 16.7 million colors
Graphics:
- AGP 4X interface with ATI Mobility Radeon 9600
- 64MB 266MHz DDR embedded memory
Audio:
- AC ’97 stereo sound with 3D sound effects; full duplex audio
- Two Internal Stereo Speakers
HDD Support:
- One 2.5”/9.5 mm 5400 RPM IDE hard disk drive with Ultra DMA 100/133 support
- Capacity Options of 40, 60, and 80GB
DVD/CD-RW Combo:
Optical Drive 24X10X8X +24X Combo CD-RW+DVD
Modem/LAN:
- 56K Soft Modem, V.90/92 support
- Broadcom 10/100 Ethernet Base T onboard; 10/100/1000 Base T (factory option)
Wireless (Optional):
- Embedded WLAN dual-band antenna.
- Wireless options include: Intel PRO/Wireless 2200BG IEEE 802.11 B/G
- Intel PRO/Wireless 2915ABG IEEE 802.11A/B/G
Card Reader:
4-in-1; supports SmartMediaTM, MultiMediaCardTM, Memory Stick®, and Secure DigitalTM memory card formats
I/O Devices:
- PCMCIA 2.1; supports one Type II card
- Touch pad with two-click buttons and scroll wheel function
- Full-sized keyboard with Microsoft Windows function keys; 19 mm keycaps with 2.5mm travel; three instant hot keys for email, Internet, and one user-programmable function
I/O Ports:
1 - IEEE 1394
1 - Microphone-in
1 - Line-in
1 - Headphone-out
1 - VGA port/Mini D-sub 15-pin for external monitor
4 - USB 2.0 Ports
1 - S-Video Out
1 - Parallel Port
1 - RJ11 Modem Connector
1- RJ45 Ethernet Connector
1 - Port Replicator Connector
1- DC-in Connector
AC/DC Adapter:
- Output: 19V DC, 3.42A, 65W
- Input: 100-240V AC, 50/60Hz Universal
Primary Battery:
- Lithium Ion, 8-cell, 4400mAh, 65Wh battery pack
- Approximately 5 hours life
Dimensions:
- 13.1 x 11.0 x 1.2 inches (W x D x H)
- 334 x 280 x 29.8 mm (W x D x H)
Weight:
6.2 lbs. / 2.8 kg
Warranty:
Three year limited warranty for parts, labor and technical support
|
