Notebook Highlights:
- Intel® Pentium® M processor up to 2.13GHz
- 15.4” Wide XGA TFT display; 1024 x 768 resolution; 16.7 million colors
- Optical Drive 24X10X8X +24X Combo CD-RW+DVD
- 5-in-1Flash Reader/Writer Slot; supports SmartMedia, MultiMediaCard, Memory Stick, Secure Digital and xD-Picture
Detailed Specifications:
Model:
O’Brien CN-8
CPU:
Intel Centrino Mobile Technology
Pentium M Processor (700 Series) 1.4 to 2.13GHz
Intel Celeron M Processor (300 Series) 1.2 to 1.5GHz
1MB or 2MB Cache (CPU dependant)
Chipset:
Intel® 915GM/PM + ICH6-M
Front Side Bus:
400/533 MHz
Memory:
- 128MB to 2GB; 400/533 MHz DDR2 SDRAM
- Two SO-DIMM sockets with 0MB memory onboard
Display:
- TFT Active Matrix Color LCD display
- 15.4” Wide XGA TFT display; 1024 x 768 resolution; 16.7 million colors,
Graphics:
- Intel Graphics 915GM /PM integrated graphics memory controller
Audio:
- AC ’97 and High Definition Audio
- 5.1 / 7.1 Channel Surround Sound
- Two Stereo Speakers
HDD Support:
- One 2.5”/9.5 mm 5400 RPM IDE hard disk drive with Ultra DMA 100/133 support
- Capacity Options of 40, 60, and 80GB
DVD/CD-RW Combo:
Optical Drive 24X10X8X +24X Combo CD-RW+DVD
Modem:
- 56K Soft Modem, V.90/92 support
LAN:
- Ethernet 10/100 Base T on-board
- Ethernet 10/100/1000 (Factory Option)
Bluetooth:
Support via USB interface
Wireless (Optional):
- Embedded WLAN dual-band antenna;
- Intel PRO/Wireless 2200BG, IEEE 802.11 b+g
- Intel PRO/Wireless 2100, IEEE 802.11 b
Card Reader:
5-in-1; supports SmartMediaTM, MultiMediaCardTM, Memory Stick®, and Secure DigitalTM and xD-Picture memory card formats
I/O Devices:
- PCMCIA 2.1; supports one Type II card
- Touch pad with four-way scroll function; two-click buttons and one scroll button
- 86/87/88 full-sized keyboard with 19 x 19 mm key caps, 2.5 mm travel; Microsoft Windows function keys; and palm rest
I/O Ports:
1 - IEEE 1394
1 - Microphone-in
1 - Line-in
1 - Headphone-out
1 - VGA port/Mini D-sub 15-pin for external monitor
4 - USB 2.0 Ports
1 - S-Video Out
1 - Parallel Port
1 - RJ11 Modem Connector
1- RJ45 Ethernet Connector
1 - Port Replicator Connector (Optional)
1- DC-in Connector
1 - IrDa Infrared Port
AC/DC Adapter:
- Output: 19V DC, 3.42A, 65W
- Input: 100-240V AC, 50/60Hz Universal
Primary Battery:
- Lithium Ion, 8-cell, 2400mAh, 65Wh battery pack
- Approx. 4.5 hours; charging time 2.5 hours (power off), 3.0 hours (power on)
System Status:
- Power On/Suspend
- Battery Charging
- Wireless LAN
- CAPs Lock
- NUM Lock
- Hard Disk & Optical Disk Drives access
Dimensions:
- 14.3 x 10.5 x 1.3 inches (W x H x D)
- 363 x 266 x 34.2 mm (W x H x D)
Weight:
6.0 lbs. / 2.75 kg
Warranty:
Three year limited warranty for parts, labor and technical support
|
